The Arc LED 240V Plug & Play PIR Sensor – 3 Ports is a high-performance motion control solution designed for fast, professional lighting installations. Engineered for flexibility and efficiency, this driver allows you to connect up to three PIR sensors via its integrated 3-port system, making it ideal for larger areas requiring extended detection coverage.
Supplied complete with one plug & play PIR sensor, mounting bracket and fixing screw, this system is ready to install straight out of the box.
Key Features
- 240V AC Input (100–240V)
- 3 x PIR Sensor Ports – connect up to three sensors
- 1 x PIR Sensor Included
- Plug & Play Connections – quick installation
- Adjustable Time Delay Settings (10s / 30s / 60s / 180s)
- Adjustable Lux Control (daylight to night-only operation)
- High Voltage Sensor Switch
- Max Load: 300W
- Available in Black or White
Multi-Sensor Capability for Larger Spaces
With three dedicated PIR input ports, this driver allows installers to expand motion detection across wider areas such as:
- Offices & meeting rooms
- Retail environments
- Corridors & stairwells
- Warehouses
- Utility rooms
- Kitchens & residential spaces
Simply connect additional compatible PIR sensors to extend coverage without complex rewiring.
Adjustable Detection & Lighting Control
The integrated control dials allow you to customise:
- Time delay – set how long lights remain on after motion stops
- Lux sensitivity – choose whether the lights activate in low light only or throughout the day
- This ensures optimal energy efficiency while maintaining convenience and safety.
Professional Plug & Play Design
The clearly marked S+ / S- ports and secure push-fit terminals make installation fast and reliable. Designed with electricians and lighting installers in mind, the system reduces wiring time while maintaining a clean, professional finish.
The supplied remote PIR sensor includes a discreet housing, cable and mounting bracket for easy positioning.
Ideal For
- LED lighting systems
- Under-cabinet lighting
- Commercial lighting control
- Energy-saving upgrades
- Retrofit motion sensor installations
What’s Included
- 1 x 240V PIR Plug & Play Driver
- 1 x PIR Motion Sensor
- Mounting bracket & fixing screw
